产品详情
LUXEON 2835 系列是紧凑型设备，可确保设计自由度及为需要高流明输出和高效率的项目提供卓越的系统总体解决方案。LUXEON 2835 系列采用行业标准尺寸，是其他 2835 产品和其他常用的中等功率产品的完美升级版本。LUXEON 2835 系列可根据应用要求定制颜色，可为众多应用提供高效率和高可靠性。该系列有两种产品可供选择：输出较高的 LUXEON 2835C 和输出较低的 LUXEON 2835E。Product performance at specified test current, Tj=25°C.
|
PRODUCT
|
VOLTAGE
|
NOMINAL CCT
|
MINIMUM CRI
|
LUMINOUS FLUX
(lm) |
TYPICAL LUMINOUS EFFICACY
(lm/W) |
TEST CURRENT
|
PART NUMBER
|
|
|---|---|---|---|---|---|---|---|---|
|
MINIMIM
|
TYPICAL
|
|||||||
| LUXEON 2835E | 9V | 6500K | 70 | 78 | 86 | 158 | 60 | L128-6570EC3500001 |
| 2200K | 80 | 59 | 65 | 119 | 60 | L128-6570EC3500001 | ||
| 2700K | 80 | 67 | 75 | 137 | 60 | L128-2780EC3500001 | ||
| 3000K | 80 | 70 | 78 | 142 | 60 | L128-3080EC3500001 | ||
| 3500K | 80 | 72 | 80 | 147 | 60 | L128-3580EC3500001 | ||
| 4000K | 80 | 74 | 82 | 150 | 60 | L128-4080EC3500001 | ||
| 5000K | 80 | 74 | 82 | 150 | 60 | L128-5080EC3500001 | ||
| 5700K | 80 | 74 | 82 | 150 | 60 | L128-5780EC3500001 | ||
| 6500K | 80 | 74 | 82 | 150 | 60 | L128-6580EC3500001 | ||
| 2200K | 90 | 50 | 55 | 102 | 60 | L128-2290EC3500001 | ||
| 2700K | 90 | 54 | 62 | 114 | 60 | L128-2790EC3500001 | ||
| 3000K | 90 | 57 | 65 | 119 | 60 | L128-3090EC3500001 | ||
| 3500K | 90 | 60 | 68 | 124 | 60 | L128-3590EC3500001 | ||
| 4000K | 90 | 62 | 70 | 128 | 60 | L128-4090EC3500001 | ||
| 5000K | 90 | 62 | 70 | 128 | 60 | L128-5090EC3500001 | ||
| 6V | 2700K | 80 | 45 | 50 | 139 | 60 | L128-2780EB3500001 | |
| 3000K | 80 | 46 | 51 | 142 | 60 | L128-3080EB3500001 | ||
| 3500K | 80 | 46 | 52 | 144 | 60 | L128-3580EB3500001 | ||
| 4000K | 80 | 47 | 54 | 150 | 60 | L128-4080EB3500001 | ||
| 5000K | 80 | 49 | 54 | 150 | 60 | L128-5080EB3500001 | ||
| 5700K | 80 | 49 | 54 | 150 | 60 | L128-5780EB3500001 | ||
| 6500K | 80 | 49 | 54 | 150 | 60 | L128-6580EB3500001 | ||
| 3V | 2700K | 80 | 23 | 25 | 137 | 60 | L128-2780EA3500001 | |
| 3000K | 80 | 24 | 27 | 148 | 60 | L128-3080EA3500001 | ||
| 3500K | 80 | 24 | 28 | 154 | 60 | L128-3580EA3500001 | ||
| 4000K | 80 | 26 | 29 | 159 | 60 | L128-4080EA3500001 | ||
| 5000K | 80 | 26 | 29 | 159 | 60 | L128-5080EA3500001 | ||
| 5700K | 80 | 26 | 29 | 159 | 60 | L128-5780EA3500001 | ||
| 6500K | 80 | 26 | 29 | 159 | 60 | L128-6580EA3500001 | ||
| 2700K | 90 | 19 | 22 | 129 | 60 | L128-2790EA3500001 | ||
| 3000K | 90 | 20 | 22 | 129 | 60 | L128-3090EA3500001 | ||
| 3500K | 90 | 20 | 23 | 135 | 60 | L128-3590EA3500001 | ||
| 4000K | 90 | 21 | 24 | 140 | 60 | L128-4090EA3500001 | ||
| 5000K | 90 | 21 | 24 | 140 | 60 | L128-5090EA3500001 | ||
| 5700K | 90 | 21 | 25 | 146 | 60 | L128-5790EA3500001 | ||
| 6500K | 90 | 21 | 25 | 146 | 60 | L128-6590EA3500001 | ||
| LUXEON 2835C | 6V | 2700K | 80 | 93 | 105 | 141 | 120 | L128-2780CB3500001 |
| 3000K | 80 | 96 | 108 | 145 | 120 | L128-3080CB3500001 | ||
| 3500K | 80 | 99 | 111 | 149 | 120 | L128-3580CB3500001 | ||
| 4000K | 80 | 103 | 115 | 155 | 120 | L128-4080CB3500001 | ||
| 5000K | 80 | 103 | 115 | 155 | ||||
